Transformer Turns Ratio and Capacitor Inductance Tester

As a professional manufacturer in China,  Weshine would like to provide you quality Transformer Turns Ratio and Capacitor Inductance Tester to handle transformer ratio detection, vector group confirmation and electrical parameter verification for all kinds of power system testing work.

It adopts full three-phase sine wave inverter output paired with a high-precision measuring module. Auto voltage regulation plus soft start & soft stop control greatly stabilizes test signals and cuts measurement errors.

The Transformer Turns Ratio and Capacitor Inductance Tester supports blind testing capability,lets technicians read ratio and vector group data without knowing the transformer’s wiring layout in advance, greatly boosting field efficiency and helping clients cut procurement costs when placing bulk orders. It works seamlessly with PT, CT, single-phase, three-phase and Z-type transformers.

Users can transfer data via Bluetooth, RS232 port or USB flash drive. The internal memory stores up to 200 groups of test logs, and records can be exported as Word files for quick report sorting and editing.

Operation Instructions

Operators connect high-voltage and low-voltage terminals according to transformer type. The system automatically detects connection mode in blind test mode. The device completes ratio measurement, vector group identification, and polarity analysis in one operation cycle.

Once testing wraps up, operators can pull data via USB or wireless links to finish inspection reports and data analysis, the editable Word files also support quick sorting for tender documents demanded by batch procurement clients.

Main Usage Scenarios

1、Transformer factory acceptance testing

2、Laboratory calibration and analysis

3、Electrical equipment quality control

4、High-voltage equipment maintenance

5、Workshop diagnostic testing

Factory procurement teams can enjoy preferential unit prices, and we welcome clients to sign long-term supply contracts for stable annual testing equipment supply.

Application Scenarios

weshine electric applies the Transformer Turns Ratio and Capacitor Inductance Tester in transformer manufacturing, power system commissioning, substation maintenance, and electrical equipment inspection.

The device supports routine testing and fault diagnosis for transformer winding issues, connection errors, and internal switch faults.

Core Test Functions

1、Transformer turns ratio testing

2、Vector group identification

3、PT and CT testing

4、Substation maintenance

5、Power system commissioning

6、Transformer factory quality control

Weshine Advantages

weshine electric designs the Transformer Turns Ratio and Capacitor Inductance Tester with full three-phase sine wave output to improve measurement accuracy and stability. The device supports blind testing to simplify field operation in complex wiring conditions.

weshine electric integrates multi-format data export to improve reporting efficiency. Built-in reverse connection and short-circuit protection safeguards the tester and on-site operators during all power testing tasks, making this model a top pick for one-stop equipment sourcing and bringing consistent repeat orders from global electrical manufacturers.
